Overhead AAAC Bare Conductor Twisted Wire 100mm2 for Power Transmission

Brand Name : Zhongdong

Model Number : AAAC

Certification : CCC,IEC,VDE,TUV,ISO

Place of Origin : Hebei，China

MOQ : Negotiable

Price : Negotiable

Payment Terms : ,L/C,T/T

Supply Ability : 500KM/Week

Delivery Time : 7-30 days based on different Qty

Packaging Details : Wooden Drum

Range Of Application : Overhead Transmission, Overhead Ground

Material : Aluminum

Drum Packing : Steel Wooden Drum

Product Name : AAC/AAAC/ACSR/ACSS/ACCC

Per Drum Weight : As per request

Voltage : up to 110KV

Contact Now

Overhead AAAC Bare Conductor Cable Twisted Wire 100mm2 for Power Transmission



Application

The twisted wire is realized by rotating the twisted single wire around the twisted wire axis at equal angular speed and moving the twisted wire forward at uniform speed. It is suitable for the occasions where the working frequency is high and the skin effect and proximity effect loss of single strand wire are too large. The use of stranded wire can reduce the operating temperature, compared with the same cross-sectional area of single strand wire, stranded wire has higher mechanical, flexibility.



Overhead AAAC Bare Conductor Twisted Wire 100mm2 for Power TransmissionOverhead AAAC Bare Conductor Twisted Wire 100mm2 for Power TransmissionOverhead AAAC Bare Conductor Twisted Wire 100mm2 for Power Transmission

Construction



Code name Item Application
AAC All-aluminium Conductor Mainly for overhead power transmission and primary and secondary distribution
AAAC All Aluminimum Alloy Conductor
ACSR Aluminium Conductor Steel Reinforced Used us bare overhead transmission cable and as primary and secondary distribution cable. ACSR/AACSR/TACSR offers optimal



Discription





Nominal Area
Stranding&Wire
Dia.
Overall Dia.
Weight
Breaking Load
DC Resistance at 20ºC
Current Rating
Aluminum
Steel
MM2
NO./MM
NO./MM
MM
KG/KM
kN
Ω/km
A
25
6/2.36
1/2.36
7.08
72.1
9.61
1.093
126
50
6/3.35
1/3.35
10.05
214.1
18.35
0.5426
185
100
6/4.72
1/4.72
14.15
394.7
32.70
0.2733
278
150
30/2.59
7/2.59
18.13
725.9
69.20
0.1828
355
150
18/3.35
1/3.35
16.75
507.4
35.70
0.1815
349
175
30/2.79
7/2.79
19.53
842.4
79.80
0.1576
386
